Product details of the cookies printing machine
Product Overview
Dedicated R&D team: our R&D members are elites who have been engaged in the manufacturing of Golden Bake cookies printing machine in the industry for many years. They have rich experience are dedicated to solving technical problems of the product. One of the focusing points of Golden Bake is to check every detail of the product. cookies printing machine of Golden Bake Biscuit Production Line can be used in different industries to meet the needs of customers in different fields. The product has captured the market opportunities and has a wide range of applications.
Product Information
With a focus on quality, Golden Bake Biscuit Production Line pays great attention to the details of cookies printing machine.
Product Characteristics
The three roller sheeter (Combination sheeter) is placed in front of the three color sheeter and behind the laminator.The combination sheeter is used to pre-roll the dough or dough sheets into suitable dough pieces which is then conveyed to the 1/2/3 gauge roller for further rolling. Our three roller sheeter is is designed in 3 sets of rolls in bigger roll diameter. The three roll sheeter is driven by inverter (Japan Panasonic) which control the drive. During the sheeting process, the rolls may evenly and smoothly transfer the dough sheet to the next process from the lower roll to the next conveyor. For our Material of scraper used for scraping roller , it is made of stainless steel which is high quality.The material of scraper used for belt is PP. It is also equipped with PLC Touch Screen in order that our worker can operate it easily and quickly. At the same time, the automation has been improved greatly. The diameter of the roller is about 400 mm,the roller guard is installed on the upper roller to reduce the possibility of cutting dough sheet. The minimum speed of the combination roller is 2 meter per minutes. There is white food grade nontoxic nylon gasket inside to prevent the dough from being polluted. As a result, we can get the dough sheet which is clean and in good quality.
-Can pre-made the dough brick without multi-layer-Avoiding the dough make bubble when go through baking oven
Product Parameters
Providing customers with a whole automatic biscuit production line machinery which from material dosing to packing.
Item | Name | Specification |
1. | Dimension | L1100mm*W2100mm*H1450mm |
2. | Weight | 3000kg per set |
3. | load request | 800kg/㎡ |
4. | Power | 1.1kW+0.75kW+0.37 kW |
5. | Wallboard thickness | δ25 |
6. | Gauge roll dimension | 350mm×2+200mm×1 |
7. | Guage roll quantity | 3 pcs |
8. | Calendaring thickness' s rang | 3～30 mm |
9. | Method of roller' s distance adjust | Electricial Adjustment |
10. | Method of controlling | Frequency speed control |
11. | Belt | PU belt （China famous brand） |
12. | Roller material | Chilled alloy |
13. | Material of roller edger | PP |
14. | Material of scraper used for scraping roller | Stainless steel (304) |
15. | Material of scraper used for belt | PP |
16. | Motor brand | SEW |
17. | Roller used for Calendaring and reducer used for belt | SEW |
18. | Method of operation | Converter (with main machine’s system) |
19. | Converter brand | Japan Panasonic |
20. | PLC Brand | Japan Panasonic |
21. | Electric control brand | Schneider |
22. | Out cover material | 304Stainless steel |
23. | Transition support board material | 304Stainless steel |
24. | Support rolls treatment | Plate environmental hard chromium |
Product Details
Providing customers with a whole automatic biscuit production line machinery which from material dosing to packing.
Pre-made the hard dough to the dough sheet and then convey it to the gauge rolls.
