Three dough roller sheeter/combination sheeter---pre-made dough sheet

这里可以自定义设置
Three dough roller sheeter/combination sheeter---pre-made dough sheet
B站不支持收货地址
B站不支持库存规格
参数暂无数据
多属性暂无数据
B站不支持优惠卷

Quantity:≥1

Payment method:TT/LC

Delivery time:30 days

Port of departure:Any port of china

Certificate:CE


Add success, do you want to check your shopping cart?

暂无分享
该产品后台详情无内容

Product Characteristics

The three roller sheeter (Combination sheeter) is placed in front of the three color sheeter and behind the laminator.The combination sheeter is used to pre-roll the dough or dough sheets into suitable dough pieces which is then conveyed to the 1/2/3 gauge roller for further rolling. Our three roller sheeter is is designed in 3 sets of rolls in bigger roll diameter. The three roll sheeter is driven by inverter (Japan Panasonic) which control the drive. During the sheeting process, the rolls may evenly and smoothly transfer the dough sheet to the next process from the lower roll to the next conveyor. For our Material of scraper used for scraping roller , it is made of stainless steel which is high quality.The material of scraper used for belt is PP. It is also equipped with PLC Touch Screen in order that our worker can operate it easily and quickly. At the same time, the automation has been improved greatly. The diameter of the roller is about 400 mm,the roller guard is installed on the upper roller to reduce the possibility of cutting dough sheet. The minimum speed of the combination roller is 2 meter per minutes. There is white food grade nontoxic nylon gasket inside to prevent the dough from being polluted. As a result, we can get the dough sheet which is clean and in good quality.

-Can pre-made the dough brick without multi-layer
-Avoiding the dough make bubble when go through baking oven

Product Parameters

Providing customers with a whole automatic biscuit production line machinery which from material dosing to packing.

Item

Name

Specification

1.

Dimension

L1100mm*W2100mm*H1450mm

2.

Weight

3000kg per set

3.

load request

800kg/㎡

4.

Power

1.1kW+0.75kW+0.37 kW

5.

Wallboard thickness

δ25

6.

Gauge roll dimension

350mm×2+200mm×1

7.

Guage roll quantity

3 pcs

8.

Calendaring thickness' s rang

3~30 mm

9.

Method of roller' s distance adjust

Electricial Adjustment

10.

Method of controlling

Frequency speed control

11.

Belt

PU belt (China famous brand)

12.

Roller material

Chilled alloy

13.

Material of roller edger

PP

14.

Material of scraper used for scraping roller

Stainless steel (304)

15.

Material of scraper used for belt

PP

16.

Motor brand

SEW

17.

Roller used for Calendaring and reducer used for belt

SEW

18.

Method of operation

Converter (with main machine’s system)

19.

Converter brand

Japan Panasonic

20.

PLC Brand

Japan Panasonic

21.

Electric control brand

Schneider

22.

Out cover material

304Stainless steel

23.

Transition support board material

304Stainless steel

24.

Support rolls treatment

Plate environmental hard chromium

Application

Biscuit production line used for automatic making biscuit.
